■ 产品说明

■ PRODUCT DESCRIPTION

● Rated temperature：105℃
● Rated voltage：300V
● Reference standard：UL758,UL1581
● Standard Conductor:28AWG tinned copper wire stranded
● PVC insulation , comply with ROHS environmental standard
● Passes UL VW-1 and JQA F-Mark flame test
● Uniform insulation thickness to ensure easy stripping and cutting
● For general purpose internal wiring of appliance

■印字
AWM 2651 E238824 VW-1 105℃ 300V 28AWG HUTAI -F- -LF-

导体
CONDUCTOR

绝缘
INSULATION

最大导体电阻
MAX.COND.
RESISTANCE
(Ω/km,20℃,DC)

规格
AWG

间距*
PITCH*
(mm

构造
CONSTR-
UCTION
(No./mm)

外径
DIA.
(mm)

芯数
(No.)

绝缘厚度
INSULATION
THICKNESS
(mm)

外径
O.D.
(mm)

28

1.00

7/0.127

0.38

2

0.27

0.90×2.00

239

3

0.27

0.90×3.00

4

0.27

0.90×4.00

5

0.27

0.90×5.00

6

0.27

0.90×6.00

7

0.27

0.90×7.00

8

0.27

0.90×8.00

9

0.27

0.90×9.00

10

0.27

0.90×10.00

11

0.27

0.90×11.00

12

0.27

0.90×12.00

13

0.27

0.90×13.00

14

0.27

0.90×14.00

15

0.27

0.90×15.00

16

0.27

0.90×16.00

17

0.27

0.90×17.00

18

0.27

0.90×18.00

19

0.27

0.90×19.00

20

0.27

0.90×20.00

21

0.27

0.90×21.00

22

0.27

0.90×22.00

23

0.27

0.90×23.00

28

1.27

7/0.127

0.38

24

0.27

0.90×24.00

25

0.27

0.90×25.00

26

0.27

0.90×26.00

27

0.27

0.90×27.00

28

0.27

0.90×28.00

29

0.27

0.90×29.00

30

0.27

0.90×30.00

31

0.27

0.90×31.00

32

0.27

0.90×32.00

33

0.27

0.90×33.00

34

0.27

0.90×34.00

35

0.27

0.90×35.00

36

0.27

0.90×36.00

37

0.27

0.90×37.00

38

0.27

0.90×38.00

39

0.27

0.90×39.00

40

0.27

0.90×40.00
