● Rated temperature：80℃
● Reference standard：DIN72551/1991
● Stranded ,tinned or bare copper conductor 0.35~6.0mm2
● PVC/EVA insulation , comply with ROHS environmental standard
● PVC jacket , comply with ROHS environmental standard
● Passes DIN 72551-5/1991 3.7.1 flame test
● Uniform insulation thickness to ensure easy stripping and cutting
● For vehicle internal wiring of appliance

绝缘
INSULATION

护套
JACKET

最大导体电阻
MAX.COND.
RESISTANCE (Ω/km,20℃,DC)

面积
CROSS
SECTION
(mm2)

构造
CONSTR-
UCTION
(No./mm)

外径
DIA.
(mm)

芯数
(No.)

绝缘厚度
INSULATION
THICKNESS
(mm)

外径
O.D.
(mm)

护套厚度
JACKET
THICKNESS
(mm)

外径
O.D.
(mm)

0.35

12/0.20

0.80

2

0.25

1.30

0.50

3.60

54.5

3

0.25

1.30

0.50

3.80

0.5

16/0.20

0.92

2

0.29

1.50

0.50

4.00

38.2

3

0.29

1.50

0.53

4.30

0.75

24/0.20

1.13

2

0.34

1.80

0.50

4.60

25.4

3

0.34

1.80

0.51

4.90

1.0

32/0.20

1.31

2

0.35

2.00

0.50

5.00

19.1

3

0.35

2.00

0.60

5.50

1.5

30/0.25

1.58

2

0.36

2.30

0.60

5.80

13.0

3

0.36

2.30

0.62

6.20

2.5

50/0.25

2.04

2

0.43

2.90

0.60

7.00

7.8

3

0.43

2.90

0.63

7.50

4.0

56/0.30

2.59

2

0.51

3.60

0.70

8.60

4.8

3

0.51

3.60

0.72

9.20

6.0

84/0.30

3.17

2

0.52

4.20

0.80

10.00

3.2

3

0.52

4.20

0.83

10.70
