● Rated temperature：80℃
● Rated voltage：300V
● Reference standard：UL758,UL1581
● Solid or stranded ,tinned or bare copper conductor 28~18AWG
● PVC insulation , comply with ROHS environmental standard
● Passes UL VW-1,cUL FT1 and JQA F-Mark flame test
● Uniform insulation thickness to ensure easy stripping and cutting
● For general purpose internal wiring of appliance

■印字 MARKING
AWM 2468 E238824 VW-1 80℃ 300V （）AWG HUTAI c AWM I A FT1 80℃ 300V （） AWG -F- -LF-

绝缘
INSULATION

最大导体电阻
MAX.COND.
RESISTANCE (Ω/km,20℃,DC)

规格
AWG

间距*
PITCH*
(mm)

构造
CONSTR-
UCTION
(No./mm)

外径
DIA.
(mm)

芯数
(No.)

绝缘厚度
INSULATION
THICKNESS
(mm)

外径
O.D.
(mm)

28

1.25

7/0.127

0.38

2

0.44

1.25×2.50

239

3

0.44

1.25×3.75

4

0.44

1.25×5.00

5

0.44

1.25×6.25

6

0.44

1.25×7.50

7

0.44

1.25×8.75

8

0.44

1.25×10.00

26

1.50

7/0.16

0.48

2

0.44

1.40×2.90

150

3

0.44

1.40×4.40

4

0.44

1.40×5.90

5

0.44

1.40×7.40

6

0.44

1.40×8.90

7

0.44

1.40×10.40

8

0.44

1.40×11.90

9

0.46

1.40×13.40

10

0.46

1.40×14.90

11

0.46

1.40×16.40

12

0.46

1.40×17.90

13

0.46

1.40×19.40

14

0.46

1.40×20.90

15

0.46

1.40×22.40

2.00

7/0.16

0.48

2

0.44

1.40×3.40

150

3

0.44

1.40×5.40

4

0.44

1.40×7.40

5

0.44

1.40×9.40

6

0.44

1.40×11.40

7

0.44

1.40×13.40

8

0.44

1.40×15.40

9

0.46

1.40×17.40

10

0.46

1.40×19.40

11

0.46

1.40×21.40

2.50

7/0.16

0.48

2

0.44

1.40×3.90

150

3

0.44

1.40×6.40

4

0.44

1.40×8.90

5

0.44

1.40×11.40

6

0.44

1.40×13.90

7

0.44

1.40×16.40

8

0.44

1.40×18.90

9

0.46

1.40×21.40

10

0.46

1.40×23.90

11

0.46

1.40×26.40

24

1.60

11/0.16

0.61

2

0.42

1.50×3.10

94.2

3

0.42

1.50×4.70

4

0.42

1.50×6.30

5

0.42

1.50×7.90

6

0.42

1.50×9.50

7

0.42

1.50×11.10

8

0.42

1.50×12.70

9

0.45

1.50×14.30

10

0.45

1.50×15.90

11

0.45

1.50×17.50

12

0.45

1.50×19.10

13

0.45

1.50×20.70

14

0.45

1.50×22.30

2.00

7/0.203

0.61

2

0.42

1.50×3.50

94.2

3

0.42

1.50×5.50

4

0.42

1.50×7.50

5

0.42

1.50×9.50

6

0.42

1.50×11.50

7

0.42

1.50×13.50

8

0.42

1.50×15.50

2.50

7/0.203

0.61

2

0.42

1.50×4.00

94.2

3

0.42

1.50×6.50

4

0.42

1.50×9.00

5

0.42

1.50×11.50

6

0.42

1.50×14.00

7

0.42

1.50×16.50

8

0.42

1.50×19.00

9

0.45

1.50×21.50

10

0.45

1.50×24.00

11

0.45

1.50×26.50

22

1.80

17/0.16

0.76

2

0.47

1.70×3.50

59.4

1.70

17/0.16

0.76

3

0.42

1.60×5.00

4

0.42

1.60×6.70

5

0.42

1.60×8.40

6

0.42

1.60×10.10

7

0.42

1.60×11.80

8

0.42

1.60×13.50

9

0.42

1.60×15.20

20

1.90

21/0.178

0.94

2

0.43

1.80×3.70

36.7

3

0.43

1.80×5.60

18

2.10

34/0.178

1.20

2

0.45

2.10×4.30

23.2

2芯 3芯 4芯 5芯 6芯 7芯 8芯 9芯 10芯 11芯 12芯

— × - · │ + - — -× │- -+ —×
