● Rated temperature：105℃
● Rated voltage：300V
● Reference standard：UL758,UL1581
● Solid or stranded ,tinned or bare copper conductor
● PVC insulation , comply with ROHS environmental standard
● PVC covering , comply with ROHS environmental standard
● Passes UL VW-1,cUL FT1 and JQA F-Mark flame test
● Uniform insulation thickness to ensure easy stripping and cutting
● For general purpose internal wiring of appliance

■ 印字

AWM 1672 E238824 VW-1 105℃ 300V （）AWG HUTAI c AWM I A FT1 105℃ 300V （） AWG -F- -LF-

绝缘
INSULATION

外绝缘
COVERING

最大导体电阻
MAX.COND.
RESISTANCE (Ω/km,20℃,DC)

耐压强度
DIELECTRIC
STRENGTH
(VAC，1min)

规格
AWG

构造
CONSTR-
UCTION
(No./mm)

外径
DIA.
(mm)

绝缘厚度
INSULATION
THICKNESS
(mm)

外径
O.D.
(mm)

护套厚度
JACKET
THICKNESS
(mm)

外径
O.D.
(mm)

28

1/0.32
7/0.127

0.32
0.38

0.44
0.46

1.20
1.30

0.40
0.40

2.00
2.10

227
239

2,000

26

1/0.404
7/0.16

0.40
0.48

0.45
0.46

1.30
1.40

0.40
0.40

2.10
2.20

143
150

2,000

24

1/0.511
11/0.16

0.51
0.61

0.49
0.49

1.50
1.60

0.40
0.40

2.30
2.40

89.3
94.2

2,000

22

1/0.643
17/0.16

0.64
0.76

0.48
0.47

1.60
1.70

0.40
0.40

2.40
2.50

56.4
59.4

2,000

20

1/0.813
21/0.178

0.81
0.94

0.44
0.48

1.70
1.90

0.40
0.40

2.50
2.70

35.2
36.7

2,000

18

1/1.024
16/0.254
34/0.178

1.02
1.17
1.20

0.44
0.47
0.45

1.90
2.10
2.10

0.40
0.40
0.40

2.70
2.90
2.90

22.2
23.2
23.2

2,000

16

1/1.29
26/0.254

1.29
1.49

0.46
0.46

2.20
2.40

0.40
0.40

3.00
3.20

14.0
14.6

2,000

14

1/1.60
41/0.254

1.60
1.88

0.45
0.46

2.50
2.80

0.40
0.40

3.30
3.60

8.78
8.96

2,000
